330D and 336D Excavator
Hydraulic System - Attachment
Printed in U.S.A.© 2010 Caterpillar, All Rights Reserved
System 17: Combined Function with Medium Pressure
330D:
GBC1-UP
GGE1-UP
THJ1-UP
PEL1-UP
LRM1-UP
ERN1-UP
RAS1-UP
T2Y1-UP
336D:
JBF1-UP
MYG1-UP
KDJ1-UP
PPN1-UP
MYP1-UP
DTS1-UP
WET1-UP
ONE POSITION TWO POSITION THREE POSITION
VENTED
PRESSURIZED
RETURN ABOVE FLUID LEVEL RETURN BELOW FLUID LEVEL
LINES CROSSING LINES JOINING
TWO - WAY THREE - WAY FOUR - WAY
SPRING CONTROL VALVES RESTRICTION LINE RESTRICTION
(FIXED)
PUMP
(2 - SECTION)
SPRING
(ADJUSTABLE)
VARIABILITY LINE RESTRICTION
(VARIABLE)
PRESSURE
COMPENSATION
PUMP
(VARIABLE & PRESSURE
COMPENSATED)
MEASUREMENT
PRESSURE TEMPERATURE FLOW
ROTATING SHAFTS
UNIDIRECTIONAL BIDIRECTIONAL
PUSH - PULL LEVER PEDALGENERAL MANUAL PUSH BUTTON SPRING
FIXED
DISPLACEMENT
VARIABLE DISPLACEMENT
NON-COMPENSATED
UNIDIRECTIONAL
BIDIRECTIONAL
VALVE ENVELOPES VALVE PORTS
FLUID CONDITIONERPUMP OR MOTOR
FLUID POWER SYMBOLS
UNIDIRECTIONAL
BIDIRECTIONAL
RELEASED PRESSURE
EXTERNAL RETURN INTERNAL RETURN
REMOTE SUPPLY PRESSURE
SIMPLIFIED
HYDRAULIC PUMPS
ACCUMULATORS
SPRING LOADED GAS CHARGED
SOLENOID
OR MANUAL
SOLENOID
& PILOT
SOLENOID &
PILOT OR MANUAL
SOLENOID SERVO THERMAL DETENT
HYDRAULIC & PNEUMATIC CYLINDERS
DOUBLE ACTINGSINGLE ACTING
BASIC
SYMBOL
SPRING
LOADED
CHECK VALVES
2 POSITION
INFINITE
POSITIONING
FLOW IN ONE
DIRECTION
FLOW IN
EITHER
DIRECTION
3 POSITION
CROSS
FLOW
PARALLEL
FLOW
INTERNAL PASSAGEWAYS
NORMAL POSITION
AB
PT
AB
PT
SHIFTED POSITION INFINITE POSITION
CONTROL VALVES
ATTACHMENT
MANUAL SHUTOFF
SHUTTLE PILOT
CONTROLLED
MAIN AUX
LINE RESTRICTION
(VARIABLE & PRESSURE
COMPENSATED)
MANUAL CONTROL SYMBOLS
HYDRAULIC MOTORS
FLUID STORAGE RESERVOIRS
CROSSING & JOINING LINES
VALVES
PILOT CONTROL SYMBOLS
COMBINATION CONTROLS
BASIC COMPONENT SYMBOLS
ENERGY TRIANGLES
HYDRAULIC PNEUMATIC
INTERNAL
SUPPLY PRESSURE
COMPLETE
FIXED
DISPLACEMENT
VARIABLE DISPLACEMENT
NON-COMPENSATED
HYDRAULIC SYMBOLS (ELECTRICAL)
ELECTRICAL SYMBOLS TABLE
325-AG135 PK-14
HARNESS IDENTIFICATION CODE THIS EXAMPLE
INDICATES WIRE 135 IN HARNESS “AG”
325-PK-14
WIRE GAUGE
WIRE COLOR
CIRCUIT NUMBER
IDENTIFICATION
WIRE NUMBER IDENTIFICATION CODES
CURRENT STANDARD
PREVIOUS STANDARD
ELECTRICAL SCHEMATIC EXAMPLE HYDRAULIC SCHEMATIC EXAMPLE
325-PK
WIRE COLOR
CIRCUIT NUMBER
IDENTIFICATION
B
WIRE
WIRE
(EXAMPLE VALVE)
CURRENT STANDARD
TRANSDUCER
(FLUID)
M
ELECTRIC MOTORTRANSDUCER
(GAS / AIR)
G
GENERATOR
PRESSURE SWITCH ELECTRICAL WIREPRESSURE SWITCH
(ADJUSTABLE)
TEMPERATURE
SWITCH
PRESSURE
SWITCH
TEMPERATURE
SWITCH
LEVEL
SWITCH
FLOW
SWITCH
ELECTRICAL SYMBOLS (ELECTRICAL)
A
CIRCUIT NUMBER
IDENTIFICATION
WIRE
COLOR
WIRE GAUGE
T
RENR9468-03
24 Page, (Dimensions: 34 inches x 28 inches)
PUMP GP
TAP LOCATIONS
2
4
18
52
52
179 21
3
35 21
41
36
2
2
11
43 19
20
6
45
7
10
21
41
17
13 14
15
32
30
31
51
28
37
9 10
14
13
15
2021
36
35
3
11
1943
51
28
37
44
5
16
18
44
16
29 40
29
40
6
45
7
5
1
1
50
50
4
40
26
24
26
24
22
32
30
31
22
38
38
33
33
39
39
SOS
CC
6
5
7
13
AA
BB
34
34
50
42
2624
2351
PP
45
22
33
LL
KK
MM
GGNN
HH
II
JJ
OO
Note A: Refer to service manual for specific cylinder information.
Description
Part
Number
Machine
Location
Schematic
Location
Accumulator Gp - Pilot Manifold 164-6981 1 B-4
Cylinder Gp - Boom Note A 2 F-5
Cylinder Gp - Bucket Note A 3 E-5
Cylinder Gp - Stick Note A 4 F-5
Filter Gp - Case Drain 126-2075 5 A-4
Filter Gp - Pilot Hydraulic 158-8987 6 A-4
Filter Gp - Return Oil 188-4140 7 B-6
Motor Gp - Hydraulic Fan 234-4638 8 C-6
Motor Gp - Left Travel 271-6376 9 F-3
Motor Gp - Right Travel 271-6376 10 F-2
Motor Gp - Swing 200-3373 11 F-7
Pump Gp - Hydraulic Fan 259-0815 12 B-3
Pump Gp - Main and Pilot 283-6116 13 A-2
Sensor As - Left Pump Press. 221-8859 14 A-2
Sensor As - Right Pump Press. 221-8859 15 B-2
Switch As - Left Travel Pilot 167-3
466 16 D-7
Switch As - Pilot Pressure 167-3466 17 A-7
Switch As - Right Travel Pilot 167-3466 18 D-6
Swivel Gp 234-4440 19 E-3
Tank As - Hydraulic Oil 239-1661 20 A-5
Valve Gp - Check, Cooler Bypass 190-7745 21 C-7
Valve Gp - Control, Auxiliary 259-7378 22 D-5
Valve Gp - ECV, Check Solenoid 297-0370 23 F-4
Valve Gp - ECV1, Check Solenoid 297-0370 24 E-4
Valve Gp - ERV1, Sol. and Relief 244-8506 26 E-4
Valve Gp - Heavy Lift Solenoid 121-6303 28 B-4
Valve Gp - Left Travel Counterbalance 204-2819 29 E-3
Valve Gp - Load Control Boom Cylinder 255-5683 30 D-1
Valve Gp - Load Control Stick Cylinder 255-5680 31 D-4
Valve Gp - Main Control 285-1345 32 C-1 to C-6
Valve Gp - Neg. Flow Control 171-0188 33 E-1
Valve Gp - Pilot Manifold 215-5037 34 B-5
Valve Gp - Pilot, Bucket and Boom 270-5952 35 B-6
Valve Gp - Pilot, Stick and Swing 270-5951 36 B-7
Valve Gp - Press. Red. Bo
om/ Swing 232-4102 37 B-4
Valve Gp - Press. Red. Bucket/ Stick 232-4102 38 A-5
Valve Gp - Pressure Relief 206-3354 39 A-5
Valve Gp - Right Travel Counterbalance 204-2819 40 E-2
Valve Gp - Shuttle 185-0462 41 A-6
Valve Gp - Shuttle 259-7732 42 B-4
Valve Gp - Swing Cushion 158-9090 43 E-7
Valve Gp - Travel Pilot 270-5947 44 D-6
Valve Gp - Work Tool, (4 Function) 259-7429 45 E-1
Pump Gp - Auxiliary, Medium Pressure 207-8235 50 B-2
Valve Gp - Control, Med. Press. 232-4103 51 F-6
Valve Gp - Solenoid and Press. Reducing 259-7430 52 E-2
Component Locations
Attachments
Tap Locations
Pressure and Sampling
Tap
Number
Description
Schematic
Location
AA Left Pump Delivery Pressure B-1
BB Right Pump Delivery Pressure B-1
CC Pilot Pump Delivery Pressure A-4
GG Pilot Pressure Pb1 (B1), Attachment F-1
HH Pilot Pressure Pa1 (B2), Attachment F-1
II Pilot Pressure bR2 (B3), Att
achment F-1
JJ Pilot Pressure aR2 (B4), Attachment F-2
KK Right Pump Pilot Pressure E-1
LL Left Pump Pilot Pressure E-1
MM Pilot Pressure MPb1 (B1), Attachment E-2
NN Pilot Pressure MPa1 (B2), Attachment E-2
OO Pump Power Shift Pressure B-1
PP Auxiliary Pump Pressure F-7
SOS Hydraulic Oil Sampling Port A-4
MACHINE COMPONENT LOCATIONS
13
LINE PATTERNS
Drain / Return Lines
Component Group
Pilot / Load Sensing Pressure
Pressure Line
Attachment
Air Line
CALLOUTS
Taps (Pressure, Sampling, Sensor - by letter)
Components (By number)
YY
52
HYDRAULIC CIRCUIT COLOR DESCRIPTIONS
PILOT PUMP OUTPUT
RIGHT MAIN PUMP OUTPUT
HEAVY LIFT CONTROL CIRCUIT
MEDIUM PRESSURE PUMP
LEFT AND RIGHT MAIN PUMP POWERSHIFT CIRCUIT
FAN PUMP AND CONTROL CIRCUIT
SUPPLY LINE
STICK CYLINDER CONTROL CIRCUIT
LEFT TRAVEL MOTOR CONTROL CIRCUIT
ATTACHMENT CONTROL CIRCUIT
SWING MOTOR CONTROL CIRCUIT
DRAIN / RETURN LINE
SWING BRAKE CONTROL CIRCUIT
RIGHT MAIN PUMP OUTPUT
TRAVEL SPEED CONTROL CIRCUIT
BUCKET CYLINDER CONTROL CIRCUIT
RIGHT TRAVEL MOTOR CONTROL CIRCUIT
BOOM CYLINDER CONTROL CIRCUIT
RENR9468-03
24 Page, (Dimensions: 34 inches x 28 inches)
THIS SCHEMATIC IS FOR THE 330D AND 336D EXCAVATOR HYDRAULIC SYSTEM
